    1. Model
    LV10-5/LV40
    LV8-4/LV64
    ELV8-4/LV64
    ELV8-4/LV64
    LV5-2/LV180
    LV5-2/LV150
Product Center
  • LV10-5/LV40

    Probe model LV10-5
    Scanning mode linear
    Number of elements 128
    Element pitch 0.300 mm
    Angle / Width 38.40 mm
    Center frequency 7.00 MHz
    Frequency range 4.50-9.50 MHz
    Scope of application Vet
  • LV8-4/LV64

    Probe model LV8-4
    Scanning mode linear
    Number of elements 80
    Element pitch 0.800 mm
    Angle / Width 64.00 mm
    Center frequency 6.00 MHz
    Frequency range 4.00-8.00 MHz
    Scope of application Vet
  • ELV8-4/LV64

    Probe model ELV8-4
    Scanning mode linear
    Number of elements 128
    Element pitch 0.501 mm
    Angle / Width 64.00 mm
    Center frequency 6.00 MHz
    Frequency range 4.00-8.00 MHz
    Scope of application Vet
  • ELV8-4/LV64

    Probe model ELV8-4
    Scanning mode linear
    Number of elements 128
    Element pitch 0.501 mm
    Angle / Width 64.00 mm
    Center frequency 6.00 MHz
    Frequency range 4.00-8.00 MHz
    Scope of application Vet
  • LV5-2/LV180

    Probe model LV5-2
    Scanning mode linear
    Number of elements 128
    Element pitch 1.390 mm
    Angle / Width 178.00 mm
    Center frequency 3.50 MHz
    Frequency range 2.00-5.00 MHz
    Scope of application Vet
  • LV5-2/LV150

    Probe model LV5-2
    Scanning mode linear
    Number of elements 128
    Element pitch 1.140mm
    Angle / Width 146.00 mm
    Center frequency 3.50 MHz
    Frequency range 2.00-5.00 MHz
    Scope of application Vet
